General | |
---|---|
Frequency Range |
VHF: 136-174MHz UHF: 350-370MHz; 400-420MHz; 450-470MHz |
Channel Capacity | 16 (15+S) |
Channel Spacing | 12.5kHz/25kHz |
Frequency Stability | ±1.5ppm |
Operating Temperature | -25℃ ~ +55℃ |
Antenna Impedance | 50Ω |
Operating Voltage | DC3.8V±10% |
Dimensions (H×W×D) | 106×57×30mm |
Weight (With Antenna & Battery) | 160g |
Battery | 2000mAh (Li-ion Battery) |
Receiver | |
Sensitivity | 0.15μV / 0.18μV |
Adjacent Channel Selectivity | 65dB / 55dB |
Intermodulation Rejection | 55dB |
Spurious Response Rejection | ≥60dB |
S/N | 40dB / 35dB |
Rated Audio Power Output | ≥600mW |
Rated Audio Distortion | ≤5% |
Transmitter | |
RF Power (H/L) | UHF: 2W/1W VHF: 2W/1W |
Modulation Type | 16KΦF3E / 8KΦF3E |
Modulation Limiting | ≤5kHz / ±2.5kHz |
FM Distortion | ≤5% |
Residual FM | -45dB / -35dB |
Adjacent Channel Power | -65dB / -55dB |
Spurious and Harmonics | ≤-36dBm |
Standard Accessories | |||||
Antenna | Li-ion Battery | Charge Adapter | Intelligent Charger | Belt Clip | Hand Strap |
Optional Accessories | |||||
Earpiece Mic | Remote Speaker Microphone | Programming Cable |
