Voice Prompts
This feature enables radio to report current channel. It brings convenience to users in special applications, such as working in the darkness.
Voice Encryption
It provides enhanced privacy to communication, effectively prevents wiretap on the channel.
Monitor
To hear a weak signal, press MONI key. And it helps adjust volume when no signal is received.
Battery Power Indication & Alert
When the function key is pressed, the radio emits a different sound to indicate the current battery level. And it also reminds user to replace or charge the battery if the battery power is low.
High/Low Power Switchable
The radio can be switched between low power and high power. When talk range is small, the radio can be switched to low power in order to save battery power.
Whisper
This function can be enabled in quiet environment and allows you to speak quietly into the radio and still be heard clearly.
Emergency Alert
Press the preset emergency key to emit emergency alarm, or send ENI or background noise to predefined person.
VOX
Hands-free operation is available when VOX function is turned ON.
PTT ID Encode
It provides identification of radio to control center, which is convenient for communication management.
Squelch Level
It minimizes interference from undesired weak signals and enables weak signals to be heard.
Scan
This feature enables radio to scan every channel in scanning list by pressing function key to activate scanning, the user can detect which channel of partner in groups is available, then transmits signal to start communication.
TOT
The feature allows for more efficient use of channels by limiting the amount of time of each transmission. Also, it effectively avoids radio damage because of long-time transmission.
Busy Channel Lockout (BCL)
BCL is used to prevent the interference with the on-going conversation.
CTCSS/CDCSS
Unique CTCSS/CDCSS is useful to setup group users to avoid unwanted conversations on the same channel.
25kHz/12.5kHz Switchable
Different channel spacing 25kHz /12.5kHz are optional to comply with the regulations of different countries.
Wired Clone
To quickly set the parameters on a radio, you can clone the radio data from another radio with the cloning cable, which saves the time of parameter setting.
PC Programming
Frequency and various features can be set by PC programming software.
General
|
Frequency Range
|
VHF: 136-174MHz
UHF: 400-470MHz; 350-390MHz
|
Channel Capacity
|
16 (15+S)
|
Channel Spacing
|
25.0kHz / 12.5kHz
|
Frequency Stability
|
±1.5ppm
|
Operating Temperature
|
-25℃ ~ +55℃
|
Antenna Impedance
|
50Ω
|
Operating Voltage
|
7.5V
|
Dimensions (H×W×D)
|
110×55×32mm
|
Weight
(With Antenna & Battery)
|
175g
|
Battery
|
1200mAh
|
Receiver
|
Sensitivity
|
0.20μV(25kHz) / 0.22μV(12.5kHz)
|
Adjacent Channel Selectivity
|
60dB@12.5kHz / 70dB@25kHz
|
Intermodulation Rejection
|
65dB
|
Conducted Spurious Emission
|
<-57dBm
|
S/N
|
35dB@12.5kHz / 45dB@25kHz
|
Rated Audio Power
Output
|
600mW
|
Rated Audio Distortion
|
≤5%
|
Transmitter
|
RF Power (H/L)
|
UHF High Power: 4W/ Low Power: 1W
VHF High Power: 5W/ Low Power: 1W
|
Modulation Type
|
16KΦF3E / 8KΦF3E
|
Modulation Limiting
|
≤2.5kHz @ 12.5kHz
≤5kHz @ 25kHz
|
FM Distortion
|
≤5%
|
Residual
FM
|
40dB@12.5kHz / 45dB@25kHz
|
Adjacent Channel Power
|
60dB@12.5kHz / 70dB@25kHz
|
Spurious and Harmonics
|
≤-36dBm(<1GHz)/-30dBm(>1GHz)
|
All specifications are tested according to applicable standards and subject to changes without notice due to continuous development.
Accessory List
Standard Accessories
|
Antenna
|
Battery
|
Charge Adapter
|
Desktop Charger
|
Belt Clip
|
Hand Strap
|
Optional Accessories
|
Earphone
|
Remote Microphone
|
Programming Cable
|
Clone Cable
|
