General | |
---|---|
Frequency Range | U/V: 136-174MHz/400-470MHz |
Channel Capacity | 199 |
Channel Spacing | 25.0kHz / 12.5kHz |
Frequency Stability | ±1.5ppm |
Operating Temperature | -25℃ ~ +55℃ |
Antenna Impedance | 50Ω |
Operating Voltage | 7.4V |
Dimensions (H×W×D) | 118×62×35mm |
Weight (With Antenna & Battery) | 230g |
Battery | 1600mAh |
Receiver | |
Sensitivity |
0.20μV(25kHz) / 0.22μV(12.5kHz) |
Adjacent Channel Selectivity |
60dB@12.5kHz / 70dB@25kHz |
Intermodulation Rejection | 65dB |
Spurious Response Rejection | 70dB |
S/N |
40dB@12.5kHz / 45dB@25kHz |
Rated Audio Power Output | ≥900mW |
Rated Audio Distortion | ≤5% |
Transmitter | |
RF Power (H/L) |
UHF High Power: 4W/ Low Power: 1W VHF High Power: 5W/ Low Power: 1W |
Modulation Type | 16KΦF3E / 8KΦF3E |
Modulation Limiting |
≤2.5kHz @ 12.5kHz ≤5kHz @ 25kHz |
FM Distortion | ≤5% |
Residual FM | 40dB@ 12.5kHz / 45dB @25kHz |
Adjacent Channel Power | -60dB |
Spurious and Harmonics |
≤-36dBm(<1GHz)/-30dBm(>1GHz) |
All specifications are tested according to applicable standards and subject to changes without notice due to continuous development.
Standard Accessories | |||||
Antenna | Battery | Charge Adapter | Desktop Charger | Belt Clip | Hand Strap |
Optional Accessories | |||||
Earphone | Remote Microphone | Programming Cable | Clone Cable |
