HQT LICENCE-FREE ANALOG SERIES TH-446PLUS

HQT TH-446PLUS is a licence-free radio compliant with PMR 446 standards. Its unique design of lightness and portability provides users with convenience and comfort even holding the radio for a long period. It has multiple programmable keys which especially make it easy to operate. Besides normal two-way radio functions, it also provides a few higher level functions for users who work in construction industry, hospitality and retailing.
  • TOT;
  • Scan;
  • CTCSS/CDCSS;
  • Emergency Alert;
  • PC Programmable;
  • Busy Channel Lockout (BCL).
TI OMAP SERIES is recommended for customized needs and requirements.

Please contact our sales consultants for more product information. Get Support >>

Voice Prompts
Voice prompts are available when switching channels and other function operation. This is specially designed for users working in the dim environment.
Voice Encryption
It provides enhanced security to public communication and private communication because of effective prevention of wiretap on the same frequency.
Whisper
Equipped with earphone you can speak quietly into the radio and still be heard clearly when this function is turned on.
Emergency Alert
Users in emergency situations can turn on this function to emit local alarm tone or send SOS message to control center or pre-defined person.
Monitor
You can press MONI key to hear a weak signal and it also helps adjust volume when no signal is received.
Battery Power Inquiry & Low Battery Alert
User can inquire residual battery power by pressing the corresponding function key. If the battery power is insufficient, user would be reminded to charge the battery.
VOX
Hands-free operation is available when VOX is on.
PTT ID
With this function, ENI would be sent when pressing or releasing PTT key so that it provides identification of radio to control center.
Scan
The radio begins scanning every channel in scanning list when this function is turned on.
TOT
The feature allows for more efficient use of channels by limiting the amount of time of each transmission. Also, it effectively avoids radio damage because of long-time transmission.
BCL
A channel which is already in use is not available to others. It is used to prevent interference with the on-going conversation.
CTCSS/CDCSS
The signaling can avoid unwanted conversations on the same channel.
Wired Clone
To quickly set the parameters, you can clone the data from one radio to another one via standard cloning cable.
PC Programmable
Frequency and various features can be set by PC programming software.
General
Frequency Range 446.00625 ~ 446.09375MHz
Channel Capacity 16
Channel Spacing 12.5kHz
Frequency Stability ±1.5ppm
Operating Temperature -25℃ ~ +55℃
Antenna Impedance 50Ω
Operating Voltage DC7.4V
Dimensions (H×W×D) 133×62×37mm
Weight (With Antenna & Battery) 230g
Battery 1500mAh (Li-ion Battery)
Receiver
Sensitivity 0.20μV
Adjacent Channel Selectivity 60dB
Intermodulation Rejection 65dB
Spurious Response Rejection ≥60dB
S/N 35dB
Rated Audio Power Output ≥600mW
Rated Audio Distortion ≤5%
Transmitter
RF Power (H/L) 0.5W
Modulation Type 8KΦF3E
Modulation Limiting ≤2.5kHz
FM Distortion ≤5%
Residual FM -35dB
Adjacent Channel Power -60dB
Spurious and Harmonics -36dBm≤1GHz; -30dBm>1GHz

Accessory List

Standard Accessories
Antenna Li-ion Battery Charge Adapter Intelligent Charger Belt Clip Hand Strap
Optional Accessories
Earpiece Mic Remote Speaker Microphone Programming Cable
