Scan
It includes Time-control scanning and carrier scanning. Priority can be set to dual-channel scanning.
Various Signaling Types
It supports various analog signaling (DTMF Encode, CTCSS/CDCSS, 2-Tone ,5-Tone and QDC-1200), provides higher function expansion capacity.
PTT ID
Press or release PTT key to send ID code with this function on, it is helpful to other radio's identification and the management of control center.
25kHz/12.5kHz Switchable
Users can set the bandwidth of each channel to 25kHz or 12.5kHz by using computer programming software and convert different bandwidths, which makes re-purchase unnecessary.
Programmable Keys
Programmable keys SK1, SK2 and TK can be programmed as call, alert, monitor, noise squelch, scan, VOX, power check, vibration prompt, flashlight and some other desired functions by user.
Voice Prompt/Power/Functions/Charge Alert with Multiple Languages
It is the model designed for working in dark environment. This feature enables it to indicate the operation status with different languages, report current channel, power indication and alert.
Emergency Alert
In case of emergency or unexpected events, it will automatically send alarm immediately while pressing the alarm button. In addition, the background or ID code can be secretly sent to notify your partners.
Lone Worker
This function provides security for individuals who work remotely from their members. If the user does not respond to indication tone, the pre-defined emergency procedure will be activated if pre-defined time expires.
VOX
Hands-free operation is available when VOX function is ON.
High/Low Power Switchable
It can be switchable between low and high power modes. When talk rang is small, it can be switched to low power mode in order to save power.
Reverse Frequency
This function can enable the radio to keep communication with other radios when trunk is closed or beyond its working range.
TOT
This function allows for more efficient use of channels by limiting the amount of time of each transmission, and it effectively avoids radio damages because of long-time transmission.
BCL
BCL is used to avoid the interference with the ongoing conversation by preventing signals from being sent to a busy channel.
Auto Battery Save
When channel is not busy or there is no operation for 12 seconds, the power saving function will be on automatically. It will turn on and off from time to time to save the power. The on/off time can be set by software.
Wired Clone
Clone the radio data from another radio with the cloning cable to make the same parameter of two radios.
PC Programming
Frequency data, function parameter and signaling can be set by PC programming software.
General
|
Frequency Range
|
VHF: 136-174MHz
UHF: 400-470MHz; 450-520MHz;
350-390MHz
|
Channel Capacity
|
16 (15+S)
|
Channel Spacing
|
25.0kHz / 12.5kHz
|
Frequency Stability
|
±1.5ppm
|
Operating Temperature
|
-30℃ ~ +60℃
|
Antenna Impedance
|
50Ω
|
Operating Voltage
|
7.4V
|
Dimensions (H×W×D)
|
118×55×34mm
|
Weight
(With Antenna & Battery)
|
252g
|
Battery
|
1600mAh
|
Receiver
|
Sensitivity
|
0.22μV(25kHz) / 0.25μV(12.5kHz)
|
Adjacent Channel Selectivity
|
60dB@12.5kHz / 70dB@25kHz
|
Intermodulation Rejection
|
65dB
|
Spurious Response
Rejection
|
70dB
|
S/N
|
40dB@12.5kHz / 45dB@25kHz
|
Rated Audio Power
Output
|
1.5W
|
Rated Audio Distortion
|
≤5%
|
Transmitter
|
RF Power (H/L)
|
UHF High Power: 4W/ Low Power: 1W
VHF High Power: 5W/ Low Power: 1W
|
Modulation Type
|
16KΦF3E / 8KΦF3E
|
Modulation Limiting
|
≤2.5kHz @ 12.5kHz
≤5kHz @ 25kHz
|
FM Distortion
|
≤5%
|
Residual
FM
|
40dB @ 12.5kHz / 45dB @25kHz
|
Adjacent Channel Power
|
-60dB
|
Spurious and Harmonics
|
≤-36dBm(<1GHz)/-30dBm(>1GHz)
|
All specifications are tested according to applicable standards and subject to changes without notice due to continuous development.
Accessory List
Standard Accessories
|
Antenna
|
Battery
|
Charge Adapter
|
Desktop Charger
|
Belt Clip
|
Hand Strap
|
Optional Accessories
|
Earphone
|
Remote Microphone
|
Programming Cable
|
Leather Case
|
