| General | |
|---|---|
| Frequency Range |
VHF: 136-174MHz UHF: 400-470MHz;450-520MHz |
| Channel Capacity/Zone Capacity |
512(32 Zones×16 Channels) |
| Channel Spacing |
25kHz/12.5kHz |
| Frequency Stability |
±1.5ppm |
|
Antenna Impedance |
50Ω |
| Operating Temperature | -25℃~+55℃ |
| Operating Voltage | 7.5V |
|
Dimensions (H×W×D) |
98×60×30mm |
|
Weight(With Antenna & Battery) |
200g |
|
Battery |
2600mAh |
| Receiver | |
| Sensitivity | Analog SINAD: 0.22μV/Digital 5%BER:0.22μV |
| Adjacent Channel Selectivity |
60dB@12.5kHz / 70dB@25kHz |
|
Intermodulation |
65dB |
| Spurious Response Rejection | 70dB |
| Hum and Noise | -40dB@12.5kHz /-45dB@25kHz |
| Conducted Spurious Emission | ≤-57dBm |
| Audio Response |
+1~-3dB |
| Audio Power Output |
0.8W |
| Transmitter | |
| RF Power |
UHF High Power: 4W /Low Power: 1W VHF High Power:5W /Low Power:1W |
| Modulation Limiting |
≤2.5kHz
@ 12.5kHz ≤5kHz @ 25kHz |
| Conducted/Radiated Emission | ≤-36dBm(<1GHz) / -30dBm(>1GHz) |
| Adjacent Channel Power | 60dB @ 12.5kHz/70dB @ 25kHz |
| Audio Response | +1~-3dB |
| Audio Distortion | ≤3% |
| Frequency Stability |
±1.5ppm |
| FM Modulation |
11KΦF3E @ 12.5kHz 16KΦF3E @ 25kHz |
| 4FSK Digital Modulation |
12.5kHz Data: 7K60F1D and 7K60FXD 12.5kHz Voice: 7K60F1E and 7K60FXE 12.5kHz Voice&Data: 7K60F1W |
| Digital Vocoder Type | AMBE+2TM |
| Digital Protocol | ETSI TS102 361-1.-2.-3 |
All specifications are tested according to applicable standards and subject to changes without notice due to continuous development.
| Standard Accessories | |||||
| Antenna | Battery | Charge Adapter | Desktop Charger | Belt Clip | Hand Strap |
| Optional Accessories | |||||
| Earphone | Remote Microphone | Programming Cable | Clone Cable | ||
